Transistors - Bipolar (BJT) - Arrays, Pre-Biased

XN0121400L

part stock: 1463

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, Resistor - Emitter Base (R2): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 80 @ 5mA, 10V,

To Wishlist

UP0331200L

part stock: 1401

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 22 kOhms, Resistor - Emitter Base (R2): 22 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 60 @ 5mA, 10V,

To Wishlist

UP0431100L

part stock: 1391

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, Resistor - Emitter Base (R2): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 35 @ 5mA, 10V,

To Wishlist

XN0121600L

part stock: 1436

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 4.7 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 160 @ 5mA, 10V,

To Wishlist

DMC264010R

part stock: 104219

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, Resistor - Emitter Base (R2): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 35 @ 5mA, 10V,

To Wishlist

NP043A300A

part stock: 1509

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 80mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 47 kOhms, Resistor - Emitter Base (R2): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 80 @ 5mA, 10V,

To Wishlist

XP0111400L

part stock: 137234

Transistor Type: 2 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, Resistor - Emitter Base (R2): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 80 @ 5mA, 10V,

To Wishlist

DMG564050R

part stock: 114333

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 160 @ 5mA, 10V,

To Wishlist

DMC564000R

part stock: 147505

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 160 @ 5mA, 10V,

To Wishlist

XN0F26100L

part stock: 1476

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 600mA, Voltage - Collector Emitter Breakdown (Max): 20V, Resistor - Base (R1): 3.3 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 50mA, 5V,

To Wishlist

XN0121500L

part stock: 1456

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 160 @ 5mA, 10V,

To Wishlist

XP0421500L

part stock: 106511

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 160 @ 5mA, 10V,

To Wishlist

XN0421000L

part stock: 3141

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 160 @ 5mA, 10V,

To Wishlist

Rohm Semiconductor

UMD4NTR

part stock: 139055

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 4.7 kOhms, 10 kOhms, Resistor - Emitter Base (R2): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 68 @ 5mA, 5V,

To Wishlist

Rohm Semiconductor

UMH7NTR

part stock: 166319

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 4.7 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 1mA, 5V,

To Wishlist

RN1910FE(T5L,F,T)

part stock: 1466

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 4.7 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 120 @ 1mA, 5V,

To Wishlist

RN4905T5LFT

part stock: 3212

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 2.2 kOhms, Resistor - Emitter Base (R2): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 80 @ 10mA, 5V,

To Wishlist

RN4904(T5L,F,T)

part stock: 1532

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 47 kOhms, Resistor - Emitter Base (R2): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 80 @ 10mA, 5V,

To Wishlist

RN1501(TE85L,F)

part stock: 179912

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 4.7 kOhms, Resistor - Emitter Base (R2): 4.7 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 30 @ 10mA, 5V,

To Wishlist

RN2971(TE85L,F)

part stock: 187083

Transistor Type: 2 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 120 @ 1mA, 5V,

To Wishlist

RN4610(TE85L,F)

part stock: 196797

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 4.7 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 120 @ 1mA, 5V,

To Wishlist

RN4990(T5L,F,T)

part stock: 196989

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 4.7 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 120 @ 1mA, 5V,

To Wishlist

RN1909(T5L,F,T)

part stock: 1368

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 47 kOhms, Resistor - Emitter Base (R2): 22 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 70 @ 10mA, 5V,

To Wishlist

ON Semiconductor

MUN5332DW1T1

part stock: 1515

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 4.7 kOhms, Resistor - Emitter Base (R2): 4.7 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 15 @ 5mA, 10V,

To Wishlist

ON Semiconductor

SMUN5233DW1T1G

part stock: 139425

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 4.7 kOhms, Resistor - Emitter Base (R2): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 80 @ 5mA, 10V,

To Wishlist

ON Semiconductor

SMUN5313DW1T1G

part stock: 106685

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 47 kOhms, Resistor - Emitter Base (R2): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 80 @ 5mA, 10V,

To Wishlist

Diodes Incorporated

DCX114TU-7-F

part stock: 152977

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 1mA, 5V,

To Wishlist

Diodes Incorporated

DIMD10A-7

part stock: 110378

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, 500mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, 100 Ohms, Resistor - Emitter Base (R2): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 1mA, 5V,

To Wishlist

Diodes Incorporated

UMC4NQ-7

part stock: 189936

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 47 kOhms, 10 kOhms, Resistor - Emitter Base (R2): 47 kOhms, 47 kOhms,

To Wishlist

PBLS4003D,115

part stock: 164626

Transistor Type: 1 NPN Pre-Biased, 1 PNP, Current - Collector (Ic) (Max): 100mA, 700mA, Voltage - Collector Emitter Breakdown (Max): 50V, 40V, Resistor - Base (R1): 10 kOhms, Resistor - Emitter Base (R2): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 30 @ 5mA, 5V / 300 @ 100mA, 5V,

To Wishlist

PBLS4005Y,115

part stock: 199204

Transistor Type: 1 NPN Pre-Biased, 1 PNP, Current - Collector (Ic) (Max): 100mA, 500mA, Voltage - Collector Emitter Breakdown (Max): 50V, 40V, Resistor - Base (R1): 47 kOhms, Resistor - Emitter Base (R2): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 80 @ 5mA, 5V / 150 @ 100mA, 2V,

To Wishlist

PUMD9,115

part stock: 126189

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, Resistor - Emitter Base (R2): 47 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 5mA, 5V,

To Wishlist

PRMH11Z

part stock: 116135

Transistor Type: 2 NPN - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, Resistor - Emitter Base (R2): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 30 @ 5mA, 5V,

To Wishlist

PUMD4,115

part stock: 188253

Transistor Type: 1 NPN, 1 PNP - Pre-Biased (Dual), Current - Collector (Ic) (Max): 100mA, Voltage - Collector Emitter Breakdown (Max): 50V, Resistor - Base (R1): 10 kOhms, DC Current Gain (hFE) (Min) @ Ic, Vce: 200 @ 1mA, 5V,

To Wishlist
